Click Image for Datasheet
VAM - P
Vario filling machine motordriven with Impeller filling head for pasty, high viscosity and liquid products
dosing volume: 20 – 1000 ml
funnel: 18 liter
output: 400 – 1800 pieces per hour
Click Image for Datasheet
Vario filling machine motoerdriven with peristaltic filling head for all liquids,
electronically adjustably
dosing volume: 1 – 2500 ml
accuracy +/- 0,5%
output: 400 – 2000 pieces per hour
Click Image for Datasheet
pneumatic closing machine for pl-tubes and laminate tubes up to 60mm with
pneumatic coding and cutting drive,
double side impulse heating
output: 400-800 tubes per hour
Click Image for Datasheet
KDH 200
piston filling machine handoperated for all liquids, high viscosity and soft paste products,
dosing volume: 20 – 200 ml
funnel volume: 18 litre
accuracy: +/-1,5%
output: 400 – 800 fillings per hour
option:
* extra piston to fill up 5 – 25 ml
output: 400 – 1000 fillings per hour
* stir tool, heating blanket for funnel
* other product tank
Click Image for Datasheet
KDP 250
piston filling machine pneumatical driven for pasty, high viscosity and liquid and soft paste products
dosing volume: 20 – 250 ml
funnel volume: 18 litre
accuracy: +/-1%
output: 400 – 1200 fillings per hour
option:
* extra piston to fill up 5 – 25 ml
output: 400 – 1200 fillings per hour
* stir tool, heating blanket for funnel
* other product tank
Click Image for Datasheet
pneumatic closing machine for metal tubes to 45mm diameter
double fold steplessly adjustable, tube fold up to 8mm broad,
up to 8 digit batch number
output: 400 – 1200 tubes per hour
Click Image for Datasheet
handoperated closing machine for metal tubes up to 45mm diameter,
doble fold steplessly adjustable, tube fold up to 8mm broad,
up to 8 digit batch number
output: 400 – 800 tubes per hour
Click Image for Datasheet
syringe filling device elektropneumatically
singleholder and doubleholder for syringes from
1ml to 60ml
up to 1000 fillings per hour
